| l: Lead Da: Ball Dia. n: Number of circuits K: Stiffness (kgf/µm) Ca: Basic Dynamix Rating Load (kgf) Coa: Basic Static Rating Load (kgf) |
|||||||||||||||||
| Model No. |
Dimensions
|
||||||||||||||||
|
d
|
l
|
Da
|
D
|
A
|
B
|
L
|
W
|
X
|
G
|
H
|
Q
|
n
|
Ca
|
Coa
|
K
|
||
| SFU1605-4 |
16
|
5
|
3.175
|
28
|
48
|
10
|
50
|
38
|
5.5
|
44
|
40
|
M6
|
4
|
780
|
1790
|
20
|
|
| * | SFU1610-3 |
16
|
10
|
3.175
|
28
|
48
|
10
|
57
|
38
|
5.5
|
44
|
40
|
M6
|
3
|
721
|
1249
|
15
|
| * | SFU2005-4 |
20
|
5
|
3.175
|
36
|
58
|
10
|
51
|
47
|
6.6
|
51
|
44
|
M6
|
4
|
1130
|
2380
|
25
|
| * | SFU2505-4 |
25
|
5
|
3.175
|
40
|
62
|
10
|
51
|
51
|
6.6
|
55
|
48
|
M6
|
4
|
1280
|
3110
|
35
|
| SFU2510-4 |
25
|
10
|
4.762
|
40
|
62
|
15
|
85
|
51
|
6.6
|
55
|
48
|
M6
|
4
|
1944
|
3877
|
33
|
|
| * | SFU3205-4 |
32
|
5
|
3.175
|
50
|
80
|
12
|
52
|
65
|
9
|
71
|
62
|
M6
|
4
|
1450
|
4150
|
40
|
| SFU3210-4 |
32
|
10
|
6.350
|
50
|
80
|
12
|
90
|
65
|
9
|
71
|
62
|
M6
|
4
|
3390
|
7170
|
40
|
|
| * | SFU4005-4 |
40
|
5
|
3.175
|
63
|
93
|
14
|
55
|
78
|
9
|
81.5
|
70
|
M8
|
4
|
1610
|
5330
|
49
|
| SFU4010-4 |
40
|
10
|
6.350
|
63
|
93
|
14
|
93
|
78
|
9
|
81.5
|
70
|
M8
|
4
|
3910
|
9520
|
50
|
|
| SFU5010-4 |
50
|
10
|
6.350
|
75
|
110
|
16
|
93
|
93
|
11
|
97.5
|
85
|
M8
|
4
|
4450
|
12500
|
65
|
|
| * | SFU6310-4 |
63
|
10
|
6.350
|
90
|
125
|
18
|
98
|
108
|
11
|
110
|
95
|
M8
|
4
|
5070
|
16600
|
80
|
| * | SFU8010-4 |
80
|
10
|
6.350
|
105
|
145
|
20
|
98
|
125
|
14
|
127.5
|
110
|
M8
|
4
|
5620
|
21300
|
90
|
