| l: Lead Da: Ball Dia. n: Number of circuits K: Stiffness (kgf/µm) Ca: Basic Dynamix Rating Load (kgf) Coa: Basic Static Rating Load (kgf) |
||||||||||||||||||
| Model No. |
Dimensions
|
|||||||||||||||||
|
d
|
l
|
Da
|
D
|
A
|
B
|
L
|
W
|
H
|
X
|
Y
|
Z
|
Q
|
n
|
Ca
|
Coa
|
K
|
||
| SFI1605-4 |
16
|
5
|
3.175
|
30
|
49
|
10
|
50
|
39
|
34
|
4.5
|
8
|
4.5
|
M6
|
4
|
780
|
1790
|
20
|
|
| * | SFI1610-3 |
16
|
10
|
3.175
|
34
|
58
|
10
|
57
|
45
|
34
|
5.5
|
9.5
|
5.5
|
M6
|
3
|
833
|
1249
|
15
|
| * | SFI2005-4 |
20
|
5
|
3.175
|
34
|
57
|
11
|
51
|
45
|
40
|
5.5
|
9.5
|
5.5
|
M6
|
4
|
1130
|
2380
|
25
|
| * | SFI205T-4 |
20
|
5.08
|
3.175
|
34
|
57
|
11
|
51
|
45
|
40
|
5.5
|
9.5
|
5.5
|
M6
|
4
|
1130
|
2380
|
25
|
| * | SFI2505-4 |
25
|
5
|
3.175
|
40
|
63
|
11
|
51
|
51
|
46
|
5.5
|
9.5
|
5.5
|
M8
|
4
|
1280
|
3110
|
35
|
| * | SFI3205-4 |
32
|
5
|
3.175
|
46
|
72
|
12
|
52
|
58
|
52
|
6.5
|
11
|
6.5
|
M8
|
4
|
1450
|
4150
|
40
|
| SFI3210-4 |
32
|
10
|
6.35
|
54
|
88
|
15
|
90
|
70
|
62
|
9
|
14
|
8.5
|
M8
|
4
|
3390
|
7170
|
40
|
|
| * | SFI4005-4 |
40
|
5
|
3.175
|
56
|
90
|
15
|
55
|
72
|
64
|
9
|
14
|
8.5
|
M8
|
4
|
1610
|
5330
|
49
|
| SFI4010-4 |
40
|
10
|
6.35
|
62
|
104
|
18
|
93
|
82
|
70
|
11
|
17.5
|
11
|
M8
|
4
|
3910
|
9520
|
50
|
|
| SFI5010-4 |
50
|
10
|
6.35
|
72
|
114
|
18
|
93
|
92
|
82
|
11
|
17.5
|
11
|
M8
|
4
|
4450
|
12500
|
65
|
|
| * | SFI6310-4 |
63
|
10
|
6.35
|
85
|
131
|
22
|
98
|
107
|
95
|
14
|
20
|
13
|
M8
|
4
|
5070
|
16600
|
80
|
| * | SFI8010-4 | 80 | 10 | 6.35 | 105 | 150 | 22 | 98 | 127 | 115 | 14 | 20 | 13 | M8 | 4 | 5620 | 21300 | 90 |
